Mechanical equipment of buildings; a reference book for engineers and architects (1916)
Harding, Louis Allen, Willard, Arthur C. (Arthur Cutts), 1878-1960 · New York Wiley · leaf 278
perature corresponding to 140. lb. is 353.1° F.Temperature corresponding to 48. lb. is 278.4° F.Temperature corresponding to 16.7 lb. is 218.° F.Temperature range h.p. cylinder is 353.1 — 278.4 = 74.7° F.Temperature range l.p. cylinder is 278.4 - 218. = 60.4° F. STANDARD OF PERFORMANCE FOR STEAM… … Fig. 23. Rankines Cycle. steam is assumed to be expanded adiabatically in a non-conducting cylinder without clearance,the expansion being carried down to the back-pressure line. The diagram (Fig. 23) representsthe action of steam or other vapor when operating on the Rankine cycle with complete…
Building · Heating · Ventilation
Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
