Mechanical equipment of buildings; a reference book for engineers and architects (1916)
Harding, Louis Allen, Willard, Arthur C. (Arthur Cutts), 1878-1960 · New York Wiley · leaf 117
Fig. 16. Side Discharge Hopper to Rear Ash Tunnel. … Fio. 17. Large Capacity Ash Hopper for Deep Basement; Ash Tunnel Enclosed. of a double row, or may be hung from the steelwork in a full basement. The dotted Unes indicatethe construction when used with stoker equipment. With this form of hopper, the ashes mustbe raked into the car, so that tunnel…
Building · Heating · Ventilation
