Mechanical movements, powers and devices (1911)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 162

An illustration from Mechanical movements, powers and devices, 1911, leaf 162 — 557. DISC WATER METER, « Hersey model. The disc piston. A, oscillates by thepassage of water through the disc chamber.The spindle of the disc, by its oscillatingmovement, rotates the crank and gears of theindex-wheel train. HYDRAULIC POWER AND DEVICES. iS» … 558. WATER METER, Thompson model. A swinging disc movement on ball socket, operated by a flow of water, rotates a vertical crank spindle and gear train with index liand above the diaL
