ySgd. ELECTRIC ESCAPEMENT, inwhich a positive motion is given to a clockfrom a central station by a detent and im-pulse action of the electric current. Thebell crank lever L, L and its arms T, Tare actuated by the electro magnet and al-ternately strike the pallets P, P rnoving theescapement one… … 759^. PNEUMATIC EMER-GENCY BRAKE.—Instantaneous ac-tion from air brake pressure on thepiston A, which is connected by ajointed rod to the levers E, E, throwsthe brake H in contact with the railwith great force. 204 ELECTRIC POWER AND CONSTRUCTION.
