le speed. Thesame arrangement as No. 97, with the addition ofa driving pulley of different size, and a drivenpulley attached to the friction gear on the lowershaft. The right-hand belt shifts to the nextpulley and may be straight or cross, making avariety of motions to the lower shaft. TRANSMISSION… … 100. VARIABLEGEARING. SPEED OR CONE abed a, tight pulley on outside hollow shaft.^, tight pulley on inside hollow shaft. c, tight pulley on inner or solid shaft. d, loose pulley on solid shaft. a b c\ differential spur gears for three speeds. loi. TRANSMISSION OF POWER froma horizontal shaft to two…
