Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 344
377. VIBRATING LIFT.—The revolving druirB lifts the weight W, while the crank-pin connectingrod C gives the arm A and sheave E a vibrating vettical movement. With certain proportions betweenthe size of the drum B, the distance of the crank pinand connecting arm at A, a variety of motions to thecord… … 334 MILL AND FACTORY APPLIANCES.
Mechanical movements
