An illustration from Mechanical movements, powers and devices, 1911, leaf 57 — Section III. MEASUREMENT OF POWER. Speed, Pressure, Weight, Number, Quantities, and Appliances. ^ D mc ±j 139. PRONY BRAKE, for the measurementcf power. A is power shaft and pulley, enclosedin friction blocks and strap; D, the lever; C,C,.stops to control excessive movement of the lever;B, weights…
