Mechanical movements, powers and devices (1911)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 83

An illustration from Mechanical movements, powers and devices, 1911, leaf 83 — 241. MEYER CUT-OFF VALVE.—C, D, Slide valve withperforated ports. The supplementary or cilt-off valves are adjustedto the required distances, to meet the required cut-off, by a right andleft screw, which has an index H, and wheel G, for turning the screwfor cut-off adjustment on the outside of the… … 242. SINGLE D, SLIDE VALVE,with double steam and exhaustports. Central steam ports openinto steam chest at the side of the > valve.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
