Locomotive text for engineers and firemen; a complete treatise on the engine, electric head-light and standard code of train rules (1908)
National correspondence school of railroading, Chicago. [from old catalog] · [Chicago] · leaf 277
FIG. 1—PLATE 120. … FIG. 2—PLATE 120. BROOKS TANDEM TYPE. The four-cylinder Brooks compound type locomotivesare called tandems for the reason that both pistons areoperated by the same piston rod, and the high pressurecylinders are ahead of, and connected to, the low pressurecylinders. COMPOUND LOCOMOTIVES. 267 In the…
Locomotives
