o a spring barrel. G is the drivingspur gear. The larger ratchet has a fixedcheck pawl, T; is loose on the arbor, but at-tached to the gear wheel by a curved spring,S, S. The smaller ratchet is fixed to thewinding barrel and arbor. The spring andpawl R are pivoted to the larger ratchet, and stop… … u^~^~—»—»j 288 HOROLOGICAL.
