Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 153

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 153
519. DIAPHRAGM PUMP, in which a flexi-ble diaphragm is used instead of a piston. … 520. FAIRBURN BAILING SCOOP,for low-lift drainage or irrigation. The tiltingscoop may be connected to a walking beam ordirectly to a vertical engine. 521 r PENDULUM WATER LIFT.—A double seriesof scoops with flap valves and connecting pipes.The swinging of the pendulum frame alternatelyimmerses the…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
