Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 267

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 267
or planing machines. 1006. INTERMITTENT ROTARYMOTION of a wheel by vibrating levers andpawls. B, pin-tooth wheel. A, vibrating lever. 1007. INTERMITTENT CIRCULAR MOTIONfrom a reciprocating rod. Motion varied in the ratchetwheel A by the number of teeth swept over bv thepawl B. 1008. PAWL LIFT.—By… … 1009. OSCILLATING MOTION into rotarymotion by a straight and crossed band runningon two ratchet pulleys, the ratchets of which arefast on the shaft. Each oscillation of the sectorlever gives a forward motion to the shaft. loio. CONTINUOUS ROTARY MOTIONby stop ratchet and oscillating beam.…

Mechanical movements
