Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 36

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 36
ved tangentially by in-ertia. 48/. THE INCLINED PLANEin a marine governor. Thesprocket wheel A and inclined hubare fast on the shaft. The inertiawheel and its inclined hub are freeon the shaft with its hub facepressed against the driving wheelhub by the coiled spring. Irregu-larity in the speed of…

Mechanical movements
