Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 340

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 340
1355. TOGGLE-JOINT LEVER PRESS orpunch. A type of toggle-joint used in the oldforni of printing and stamping presses. MILL AND FACTORY APPLIANCES. 329 … 1356. POWER STAMPING PRESS. —Driven^ from a pulley with crank or cam shaft. A miss im-pression is made by a stop-clutch operated by a foottreadle. 1357. HAND DRILLING MACHINE, withlever feed.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
