An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 45
82,. QUARTER TWIST BELT.—The arrows showthe direction the belt should run. 54 TRANSMISSION OF POWER. … 84. FULL TWIST BELT, or cross belt 85. FULL TWIST OR CROSS BELT,for reverse motion on driven shaft.
