Section III. MEASUREMENT OF POWER. Speed, Pressure, Whig:it. Number, Quantities, and Appliances. 139. PRONY BRAKE, for the measurementcf power. A is power shaft and pulley, enclosedin friction blocks and strap; D, the lever; C,C,stops to control excessive movement of the lever;B, weights to balance…
