634. TROMPE OR HYDRAULICAIR BLAST.—One of the early devicesfor furnishing an air blast to a forge.The falling column of water draws in airthrough the small inclined orifices at d,carrying it into the reservoir e, where itseparates, and is discharged through thetuyere pipe at b. The outlet at /… … 635. AIR COMPRES-SOR.— Elevation of duplextype, showing connectingrod and yoke frame. ^— Clayton model. AIR POWER APPLIANCES. 171
