Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 126

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 126
428. VERTICAL GASOLINE ENGINE, Webster pattern. The cylinder and waterjacket form part of the framework of the engine.A four-cycle type. … 429. VERTICAL GAS ENGINE, Root model. Four-cycle compression,with double explosion. ^ is a second-ary chamber and port, closed abouthalf-stroke, shutting off part of the chargeduring compression, which is explodedduring the impulse stroke of the piston. 120 MOTIVE POWER. 430. VERTICAL KEROSENE OIL…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
