Mechanical movements, powers, devices and appliances (1901)
Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley & company · leaf 183
649. AIR COMPRES-SOR CYLINDER, PIS-TON AND VALVES.— Pattern of the Ingersoll,Sergeant Drill Co. Takesits air through a hollow pis-ton rod at E to the interiorof the piston. The annular valves, G, G, open and close by theirmomentum. H, H, discharge valves closed by springs; J, J, waterjacket. AIR… … AIR POWER APPLIANCES. 175
Mechanical movements
