Mechanical movements, powers, devices and appliances; (1903)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 247
- limited traverse of the pinions. 933. SPIRAL GEARING.—V geanng, in whichthe teeth are at a small angle with the plane of rota-tion, makes a perfectly silent transmission of power. … 934. EXPANDING PULLEY.—The sec-tional rim pieces with their arms have a radialsliding joint on the hub arms, and are movedout or in by pins projecting into the spiralslots on the central spur-gear wheel. Themovement of the wheel r, by turning the ratchetpinion d^ moves all the sections of the…
Mechanical movements
