Mechanical movements, powers, devices and appliances; (1903)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 42
75-76. BELT LACING, fornarrow belt. Commencing at a, aon the inside of belt 75, drawingthe lacing to its centre; rove theends each way, ending at e^ e, 76. pA … 77. BELT LACING.—Com-mencing at A and ending at B.Dotted lines on outside. 78. OVER-AND-OVER LAC-ING.—Commencing at A andending at B. Diagonal on outside. 79. INTERLOCKING BELTLACING, from A to B, onceacross. A good style for smallpulleys. 80. CROSS LACING, for alight belt. 81. OVER-AND-OVER…
Mechanical movements
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
