Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 131

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 131
INE VALVE GEAR.— E, Inlet valve; F, exhaust valve. Valvesare operated by a bent lever, with slidingroller H and double cam C, which by agroove rides the roller alternately on to thecams. 446. GASOLINE VAPORIZER. — The inlet nozzle, V, is ribbed onthe outside and is enclosed in achamber through… … 3 r & 447. CARBURETTERfor making air gas fromgasoline; non-freezing. A,plan — a zig-zag series ofchambers with spaces be-tween for air circulation tokeep its vaporizing wallswarm; B, a vertical section; c, r, c, open spaces. Canton or otherflannel wrapped over wire gauze frames is pushed into…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
