3 r & 447. CARBURETTERfor making air gas fromgasoline; non-freezing. A,plan — a zig-zag series ofchambers with spaces be-tween for air circulation tokeep its vaporizing wallswarm; B, a vertical section; c, r, c, open spaces. Canton or otherflannel wrapped over wire gauze frames is pushed into… … 448. AUTOMATIC OILER.—Much in use on explosive motors. Shaft c, andcranky, with the dip wire d^ are revolved bya belt dropping the oil on the wiper e, intothe small tank^ from which it flows to thecylinder.
