Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 224

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 224
[ [^1^1:^:1^];: r:^ 836. THRUST BEARING for a pro-peller shaft. The collar brasses are set inmortices in the frame; they are made inhalves and bolted together. … 837. SILVERS MARINEGOVERNOR.—The two pairof balls are pivoted to the re-volving shaft at the centre oftheir connecting arms. Theircentrifugal tension is held andadjusted by the helical springI, and thumb-screw. The open-ing of the bails moves the sleeve, D, for controlling the valve gear.

Mechanical movements
