Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 234

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 234
riven by a clock. D andC are tension weights to take up any looseness in the gear. 880/. NOVEL STEERING GEAR on Emperor Williamsyacht Meteor.—A right and left screw shaft with links between the nuts and rudder postcap. Rudderbuffer ringsat each end ofthe shaft to 880^. SHIPS STEER-ING GEAR.—A… … take up the jar.

Mechanical movements
