Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 328

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 328
1310. FRICTION CLUTCH, outside view, with toggle-jointthrust, sleeve, and yoke lever. 13II. Section of outsidebearing, clutch, toggle joint,and sleeve. »t 322 MILL AND FACTORY APPLIANCES.
