171a. THE ST. JOHNS STEAMMETER.—An automatic recordingmeter of the amount of steam passingthrough it for all purposes. The lift-ing of a conical valve by differentialpressure operates a marking indexthrough the lever on a small transfershaft through the projecting arm fromthe cylinder. See detailed…
