The modern gas tractor, its construction, utility, operation and repair: a practical treatise defining every branch of up-to-date gas tractor engineering, driving and maintenance in a non-technical manner. Considers fully all types of power plants and their components, methods of drive and speed changing mechanisms. Describes design and construction as well as practical application of tractors in the field (1919)
Pagé, Victor Wilfred, 1885-1947 · New York : Scientific American Pub. Co. · leaf 211
arting andin event of emergencies in which the mechanical genera-tor might get out of order. The four igniters are con-nected to a common conductor or bus bar which isinsulated from the metal portions of the engine andwhich is connected to the top of the switch lever bymeans of a single wire. A… … Battery h-CcO Mag/ietO Battery Fig. 73.—Typical Four Cylinder Low Tension Igninon System. the battery terminals is attached to the frame or baseof the engine and one of the magneto leads is alsogrounded. It wall be evident that when the switch lever is incentral position, as shown, neither magneto…
Farm engines · Internal combustion engines
