Modern locomotive engineering, with questions and answers .. (1913)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & co · leaf 705
FIG. 297. DISTRIBUTING VALVE AND DOUBLE-CHAMBERRESERVOIR Upper- PIPE CONNECTIONS:-Brake-Cylinder Pipe; Lower- -Brake Pipe the reservoir; also the safety valve 34, which is an essen-tial part of the distributing valve. To simplify the tracingof the ports and connections, the various positions of… … FIG. 298. THE DISTRIBUTING VALVE, DIAGRAMMATICCONNECTIONS: MR—Main-Reservoir Pipe; DH—Double-Heading- Pipe; AC—Ap-plication-Chamber Pipe; BC—Brake Cylinder Pipe; BP—Brake Pipe ET BRAKE EQUIPMENT 677 valve are illustrated in ten diagrammatic drawings; thatis, the valve is distorted to show the parts…
Locomotives
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
