Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 327
tion as the Rice single-cylinder engine. Both valves are operated by the same20 306 ENGINES, STEAM, STATIONARY RECIPROCATmG. governor through the same eccentric-rod. The valves can be set independently of each other,the low-pressure valve being arranged to admit of considerably more travel than the… … Fig. 25.—Main bearing—section. surround the entire valve. The valve can be easily operated with one liand upon the smoothvalve-steni, when under full pressure of steam. The relief-valve is in the form of a steam-tight piston, which rests on shoulders even with the valve (not on the valve itself),…
Mechanical engineering
