-faced clutches fixed on the shaft and op-erated by a lever on the steering column and a ratchet in-side the hollow shaft. By expanding one or other of theseclutches the corresponding box with its gear wheel becomesfixed to the secondary shaft, and so communicates the driveto the bevel pinion and… … 5i> +9 46 f? -M ♦* *» ♦x 39 3d 3? 30 ^ffj-f 53 3a Change Speed Gear with Friction Clutch. the center of the gear-box. It has two forward speeds and areverse. No. 55 is the primary shaft driven by the engine, and onthis shaft are mounted the driving pinions, 6 and ii, revolv-ing always with it;…
