ie overliead gears, which arenionnted on tlie milling-feed sliaft, and slide intoposition endwise upon feathered keys ; thereforecither of them may be engaged with tin; spindle-gears. Tlie feetl-shaft pulley is belted toffcd-cones. and Ihcse are connected to the platen by a pair of universal… … Fir». 2.—Circular attachment. MILLING-MACHINES. 509 respectively 18 in., 2-4 in., and 13 in, A circiilar milling attachment for this machine, shownin Fig. 3, is used in macliining gear-blanks, balance-wheels (which are milled between thespokes as well as the periphery), pistons, and such other…
