dshown in fig. 19, theend of this lever alsobeing attached to astrong adjustable spiralspring (not shown)which keeps the clutchengaged on the fly-wheel, allowance forthis drawing backbeing made as shownat E, the shaft beingin two pieces, the endsconnected by the slide-block F. The driving-shaft… … 2o6 , MOTORS AND MOTOR-DRIVING when moved by a hand lever at the side of the car, which is con-nected up with the slide collar j (fig. 19), Thus all three gearwheels revolve at the same speed as the engine. Immediatelyabove this shaft, as shown in fig. ig, is a second shaft arrangedparallel to it.…
