curve through the spots andyou have a complete expansion of the doubling plate. This platemay be ordered in two pieces. Expansion of a Mast Tube.—In Fig. 88, A B C D is the masttube. Make D E square to D C. Produce centre of the mast andfrom F as centre describe circle of diameter D E. Divide… … Sftcioa
