It does not other-wise diiTer from any ordinary projection.It is called an Isometric Projection. InFig. 34 is shown such a projection of a IjCube. The edges in the projection will beless than 1| because of fore-shortening.In the same figure, is a drawing similar tothe projection, but larger. In… … Fig. 33. principles and methods applicable to the latter apply to it. Its peculiarities are as follows. The axes ofreference, BA, BG and BC are 120° apart, and a unit length on any one of them will measure the same as onany other. Thus the edges of the cube will all be of the same length in such a…
