Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1921)

Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 143

An illustration from Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice, 1921, leaf 143
thin disks, three pieces should always be used. Two thin piecesglued together will always warp. A still better and stronger method of making large flanges isto cut out segments, five or six for each course, and fit and glue upon a chuck and faceplate in the same way as described for the hand-wheel…
