Perspective and geometrical drawing : adapted to the use of candidates for second and third-class teachers' certificates (1887)
McGuirl, Thos. H. (Thomas H.) · Toronto, Ont. : W. Briggs · leaf 109
Fig. 66. … In first, let AB be the given line; erect at A a perpendicularand make it equal to AB; with centre C and distance CAdescribe arc AD; with centre B and distance BA describe GEOMETRICAL DRAWING. 107 arc to meet former are in D; join CD and BD, completingthe square. (Fig. 66.) (6) On a given diagonal…
Geometrical drawing · Perspective
Internet Archive · Western University Libraries · Public Domain Mark 1.0. Free to use for anything.
