Perspective and geometrical drawing adapted to the use of candidates for second and third-class teachers' certificates (1887)
McGuirl, Thomas H. [from old catalog] · Toronto, W. Briggs; · leaf 74
; join C O.V., D C.V.,A C.V., B C.V.; also O MP and M MP. Prom points K, H,where B C. V. intersects O MP and M MP, erect KN and HGparallel to BD; and through N, G draw NE and GP paral-lel to CD, Draw EL J_ ^<^ EN and KL J_ to EL, whichwill complete the plinth. For BK =^ BO and KH ^ OM;… … Fig. 40. Here take A, i to right of E, and B 4^ to right of A; onAB describe square ABDC, and divide it into sixteen equalsquares; join each angle, as shown in figure, with the C.Y.;join also E MP, cutting A C. V. in P; draw FG parallel toAC, GS J_ to GF, etc. Then FG - AK = 1, tmd GS = KJST= r,…
