MECHANICAL DRAWING 39 Exercise 38.—The astronomer tells us that the planeof the earths orbit is called the ecliptic. This is anellipse in shape. Draw an ellipse by two methods. Theupper half to be constructed as follows: AC=4j^inches. DE = 354 inches. DM = AB. M and F arecenters of all arcs on the…
