A practical course in mechanical drawing for individual study and shop classes, trade and high schools (1912)
Willard, William Franklin, 1879- · Chicago : Popular mechanics company · leaf 66
nd dimensions. 6. Fig. 64, pillow-block bearing. Three views anddimensions. 7. Fig. 65, tool post holder. Three views and di-mensions. Scale half size. 8. Fig. 66, rocker. Three views and dimensions. 9. Fig. 67, crank arm. Two views and dimensions. 10. Fig. 68, core box for pipe tee. Three views… … MECHANICAL DRAWING
Mechanical drawing
