mples shown at Figs. 106 to 113 a quarter of an inchis taken as the unit, the figures marked on the illustration givingthe number of quarter-inches in each piece. These must not be DRAWING GIBCULAB LINES. 65 taken as fixed proportions, but merely as suitable sizes for theexamples. It will be seen… … Fig. 112.-Quirked Ovolo.
