Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 134

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 134
as on each end a small lip which alternatelycovers and uncovers a small fifth port S, which enters the cylinder at HYDRAULIC POWER AND APPLIANCES. 129 each end near the head. In operation, the steam piston runs over themain port, and this small fifth port being closed by the above lip,a cushion is… … 304. IMPACT WATER-WHEEL GOVERNOR. A con-ical valve, A, in the nozzle, B, con-trols the volume of the jet and isoperated by the piston, D, in thehydraulic cylinder C. E is a pis-ton valve and ports, taking waterpressure through passage, J, anddelivering pressure to the cylinderat C or L, as…

Mechanical movements
