The practical draughtsman's book of industrial design, and machinist's and engineer's drawing companion: forming a complete course of mechanical, engineering, and architectural drawing (1854)
Armengaud, aîné (Jacques-Eugène), 1810-1891, Armengaud, Charles A., 1813-1893, Amouroux, Jules, Cory, William Johnson, 1823-1892 · New York, Stringer & Townsend · leaf 32
ntre, and I B the radius of the smaller arc, I B K, which, together with the arc, n K, described with the centre,l, and radius, l d, equal to H c, form the lower portion of therequired figure; the lines, on, L k, which pass through therespective centres, also cut the arcs in the points of… … The pencil is at a, in an adjustable holder, capable of slidingalong the connecting-rod, b, one end of which is jointed at c, to aslider on the horizonfal bar, d, whilst the opposite end is similarlyjointed to the crank arm, e, revolving on the fixed centre, f, onthe bar. By altering the length of…
Decorative arts · Drawing
Internet Archive · Clark Art Institute Library · Public Domain Mark 1.0. Free to use for anything.
