Practical hand book of gas, oil and steam engines, stationary, marine, traction; gas burners, oil burners, etc.; farm, traction, automobile, locomotive; a simple, practical and comprehensive book on the construction, operation and repair of all kinds of engines (1916)
Rathbun, John B. [from old catalog] · Chicago, Charles C. Thompson co · leaf 370
er port. Both ports are supplied (JAS, OIL AND STEAM ENGINES 365 by the pipes shown by the circular openings at the right. Thesteam and oil are controlled by independent valves placed inthe two passages. In practice the oil and steam openings at the end of theburner may be either single or multiple… … Fig. 135. Showing the Different Classes of Oil Burners. for the combustion is admitted through openings in the com-bustion chamber proper, this air being supplied by natural draftor by blower. In some cases the burner is entered into the fur-nace through an opening that is much larger than the…
Internal combustion engines · Traction-engines
