Practical instructor and reference book for locomotive firemen and engineers: a practical treatise .. (1916)
Lockhart, Charles F. (Charles Fulton), b. 1872 · New York, The Norman W. Henley publishing co. · leaf 244
Fig. 76a.—Rotary Valve S-6 Independent Brake Valve. tion through the distributing valve release pipe betweenthe application cylinder of the distributing valve and portI of the automatic brake valve, so that the distributingvalve can be released by the latter. With both the auto-matic and… … Fig. 77.—S-6 Independent Brake Valve, Reference Diagram.16 242 k • I 19 f
Locomotives
