Hale, Joseph W. L. (Joseph Woodwell Ledwidge), 1886- · New York [etc.] McGraw-Hill book company · leaf 225
Rivetsin 5ilear BOILER SHELL Fig. 188. and (6) Bending or flexure which is a combination oftension and compression with or without shearing. Theexamples (Figs. 188,189 and 190) show the various stressesof materials in service. rfi M … Plaie Sliear PuncliFig. 189. bhearSiiear on Pin Since the tensile stress set up in a material is due to apull, the tensile strength of the material is a measure ofthe resistance offered by its fibers to being pulled apart. STRENGTH OF MATERIALS 211 Since the compressive stress is a stress set up in…
Mechanics, Applied
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
