Practical mechanical drawing and machine design self taught .. (1907)
Westinghouse, Charles. [from old catalog] · Chicago, F. J. Drake & co. · leaf 115
SECTION AT A.B. … Pig. 201—Shaft-hanger with Adjustable Bearing. MACHINE DESIGN 113 brasses, -which have flanges on each side, are tight-ened up by a wedge-shaped block attached by twopins to a bolt screwed at both ends.
Mechanical drawing · Machine design
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
