Practical mechanical drawing and machine design self taught .. (1907)
Westinghouse, Charles. [from old catalog] · Chicago, F. J. Drake & co. · leaf 61
57 Fig. 132. fe in Fig. 131, and with f in Fig. 132 as a center,draw the smaller arc e. Take the length of oneside of the base from c to b, Fig. 131, and mark offthe same four times on the circle hdk at h, g, d, i, k. 58 MECHANICAL DRAWING Draw through these points to the center f, jointhese points… … Ta develop a rectangular taper-sided tray. The vertical height and one-half the plan are shown inFig. 133. Draw the horizontal line bd and the per-pendicular line op as in Fig. 134. Draw the rec-tangle efgh the same size as efgh in Fig. 133. Takethe length ab as in Fig. 133 and mark off a…
Mechanical drawing · Machine design
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
