Practical mechanical drawing and machine design self taught .. (1907)
Westinghouse, Charles. [from old catalog] · Chicago, F. J. Drake & co. · leaf 92
o bo •l-l or steam under high pressure. The plug in thisexample is hollow, and is prevented from comingout by a cover which is secured to the casing by … «- — f _ L - 1J 11 11 1 -A --> Fig. 172—Details of Tailstocls., 90 MECHANICAL DRAWING four stud bolts. An annular ridge of rectangularsection projecting from the under side of thecovei, and fitting into a corresponding recess onthe top of the casing, serves to ensure that the cov-er and plug are…
Mechanical drawing · Machine design
