Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 306
oulder, or sloping downward and ARCHITECTURAL DRAFTING 261 backward. This is the diagonal of a cube. Theprojections of this diagonal in the vertical planeand in a horizontal plane are at 45 degrees, whilethe true angle of the diagonal with the plane isslightly less than 35 degrees 16 minutes. If…
Architecture · Building
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
